Drain KIT - SQUARE DRAIN KIT Showertec - 2d files - 3d files

PRODUCT DESCRIPTION

Drain KIT - SQUARE DRAIN KIT Showertec Showertec STC - SQUARE DRAIN KIT is a shower kit for vertical drains that contains the grid support system (plastic) and the grid (stainless steel or aluminium). The system combined with the STC shower trays and STC Flange kit allows you to create shower systems with point drainage and central drain.

SUPPLIER: PROFILITEC

TYPE: ACCESSORIES

HTTPS://US.PROFILITEC.COM

[email protected]
