JOINTEC GH joints with aluminium structure - 2d files - 3d files

PRODUCT DESCRIPTION

JOINTEC GH joints with aluminium structure JOINTEC GH aluminium sliding expansion joints are structural profiles conceived for intense truck and forklift passage in civil and industrial applications. They are designed to bear loads of large scale buildings or building compounds. Installed in the interstitial space between two sections of a building or between two bays, this technical joint links interspaces, moving three-dimensionally to accommodate a building’s structural and material settlement. The structural bays defined by this profile should be further subdivided with smaller scale movement / expansion joints, chosen according to the expected use and flooring type. For further information. Detailed installation instructions supplied upon request.

SUPPLIER: PROFILITEC

TYPE: ACCESSORIES

HTTPS://US.PROFILITEC.COM

[email protected]

LIST OF FILES:

Jointec GH - Datasheet - Profilitec_Catalogue-page_Jointec-GH_NA.pdf
